A wide array of unique image-processing technologies combine to produce realistic, lifelike images.
Panasonic's PT-DZ6710, 1-chip DLP™ projectors now offer even brighter and more vivid images with full high definition resolution. Along with the RGB Booster, which combines high brightness and superb color reproduction, a host of technologies work together to enhance image quality. The Dual-Lamp System and Auto Cleaning Filter extend operating stability and contribute to reliability. The PT-DZ6710 include Geometric Adjustment for projecting images onto curved screens, as well as standard HD-SDI signal compatibility. All models offer high image quality and easy system expansion to increase system integration flexibility.
Vivid Picture Quality with High Brightness
RGB Booster Significantly Improves Color Reproduction The RGB Booster achieves high image quality with levels of color reproduction (up to 145% that of conventional models) and brightness that make each color stand out. It combines Panasonic's proprietary Vivid Color Control technology with a newly engineered Lamp Modulation Drive System for a 1-chip DLP™ projector that produces bright and vivid colors.
- Vivid Color Control This unique control technology optimizes the use of the color segment areas of the color wheel. It increases the brightness of each RGB color by minimizing the unallocated portions between the colors, to achieve truly vivid coloring.
- Lamp Modulation Drive System With the new lamp modulation technology, the projector is now able to control the lamp intensity for each of the red, green, blue, and white segments of the color wheel separately. Because the actual light output is controlled in relation to each color segment, light usage is optimized and color balance is obtained without lowering the brightness. This results in bright vivid images with increased color fidelity.
Geometric Adjustment for Specially Shaped Screens This function adjusts the image for projection onto spherical, cylindrical and other specially shaped screens. You can make the adjustment easily using just the remote control, with no external equipment needed. Used together with the multi-screen support system, Geometric Adjustment expands your application possibilities, letting you create a wide range of image effects for digital signage, concerts, performances and other special events.
High Brightness with New AC Lamp Our newly-developed 300-watt AC lamps are used in the PT-DW6300. The high-efficiency light convergence technology and the color wheel work together to achieve the high brightness of 6,000 lm for the PT-DW6300.Clear, crisp images are reproduced even in bright rooms.
Detail Clarity Processor Brings Depth and Clarity to Details This advanced image-processing circuit analyzes the video signal frequency range for each scene by extracting data on the distribution of high, mid, and low-frequency components, and brings out fine details accordingly. The resulting images have a more natural, three-dimensional appearance with crisp, clear detail.
System Daylight View 2 for Enhanced Color Perception Image details are less clear when a projector is used in a room with the lights on. Panasonic's System Daylight View 2 improves brightness perception by adjusting sharpness, Gamma curves, and color corrections. This produces crisper, more stunning images with vivid colors even under bright conditions.
3D Color Management System To increase visual impact, projector images are often viewed from a comparatively close position relative to the screen size. The characteristics of the human eye, however, tend to cause changes in colors when images are viewed close-up on a large screen. Changes in color saturation, hue, and brightness differ from color to color, and conventional projectors were not able to make the appropriate corrections. 3D Color Management makes these corrections to produce accurate colors that are very close to the original images even when viewed on a large screen.
Dynamic Sharpness Control The dynamic sharpness control circuit adjusts the video signal waveforms based on the difference in brightness of adjacent pixels for a sharp, clear picture that is relatively unaffected by signal noise
Full 10-bit Picture Processing The use of a full 10-bit image processing system provides smooth tonal expression. For example, skin tones appear natural and true to life.
More Effective Noise Reduction Images are noticeably clearer, thanks to higher-performance frame noise reduction, which lowers image graininess, and improved MPEG noise reduction, which suppresses the block noise and mosquito noise that are common in fast-action scenes.
Progressive Cinema Scan (3/2 Pulldown) This interlace/progressive conversion technology automatically detects when the input signal is derived from filmed material and selects the optimum progressive processing method to assure faithful reproduction of the original image. Easy Maintenance and Superior Reliability Dual-Lamp System Prevents Image Interruptions The Dual-Lamp System increases brightness and eliminates the need to interrupt a presentation if lamp should burn out (in dual-lamp operation mode). The Lamp Relay mode also operates the lamps alternately to enable 24/7 projector operation.
Liquid Cooling System Attains a High Level of Reliability The liquid cooling system directly cools the DLP™ chip to improve performance and enable operation up to 113°F/45°C. This allows use in a wider variety of environments, while stabilizing performance and keeping the unit quiet even in harsh conditions.
Auto Cleaning Filter Reduces Maintenance Hassles The Auto Cleaning Filter (ACF) provides a clean filter surface whenever it senses clogging, and brushes dust from the filter. This enhances the Micro Cut Filter's performance, so no filter replacement is needed for over 10,000 hours*, reducing maintenance
System Integration Flexibility
Flexible Installation The wide adjustment range of the powered horizontal/vertical lens shift function assures virtually distortion-free images and adds convenience and versatility. It lets you easily make adjustments with the remote control. The unit can also be rotated 360° vertically. This means you can install it at any angle you want, to accommodate different installation conditions.
Side-by-Side Function The PT-DW6300 can simultaneously display images from two sources* onto a single screen. For example, you can display a PC image on the left and a video image on the right. Taking advantage of the wide-screen projection, this function gives you a host of new application possibilities to explore.
Web Browser Control/Monitoring and E-mail Message Alert The PT-DW6300 can be easily operated remotely over a LAN network, because it is all done using the computer's familiar web browser. Furthermore, the projector sends an e-mail message to notify the operator when an error has occurred, or a lamp needs to be replaced.
PJLink™ Compatibility The LAN terminals support PJLink™ Class 1 connection, which is highly convenient for system construction.
Multi Projector Monitoring & Control Software Panasonic's original "Multi Projector Monitoring & Control" freeware allows the user to control and monitor multiple projectors at the same time via LAN. Projectors can be scheduled to turn on and off at a certain hour everyday. When a problem occurs, an alarm message is sent to the monitoring/controlling PC.
Multi-Screen Support System Seamlessly Connects Multiple Screens - Edge Blending The edges of adjacent screens can be blended and their luminance controlled. - Color Matching This function corrects for slight variations in the color reproduction range of individual projectors. - Multi-screen Processor The PT-DW6300 can project large, multi-screen images without any additional equipment. Up to 100 units (10 x 10) can be edge-blended at a time.
Multi Projector Monitoring & Control Software Panasonic's original "Multi Projector Monitoring & Control" freeware allows the user to control and monitor multiple projectors at the same time via LAN. When a problem occurs, an alarm message is sent to the monitoring/controlling PC.
Powered Vertical/Horizontal Lens Shift A wide adjustment range of the horizontal/vertical lens shift assures virtually distortion-free images and adds convenience and versatility. It lets you easily make adjustments with the remote control, making it optimal for ceiling-mounted applications.
Ecology-conscious Design Panasonic works from every angle to minimize environmental impact in the product design, production and delivery processes, and in the performance of the product during its life cycle. The PT-DW6300 reflects the following ecological considerations.
- No halogenated flame retardants are used in the cabinet. - Lamp power switching further reduces power consumption. - Auto Power Save activates standby mode when no signal is input. - Standby power consumption of only 0.2 W has been achieved.
